Major Features

• Lightweight for carrying and Easy-To-Use.
• Silicon rubber shell protection and stable bracket for table usage.
• Using DB9 type connector compatible with Nellcor Spo2 Sensor.
• Support the oximeter probe for adult, neonate and infant.
• Big size 2.8 inch color TFT LCD display for SPO2/PR/Pulse bargraph/ plethysmogram.
• Visual and sound alarm function.
• Adjust the parameters in friendly menu.
• Low Battery voltage indicator.
• Automatically switch off within 3 minutes when no signal.
• Inner Flash memory can store testing result up to 360 hours.
• USB interface support upload the data to computer and review the history data with software in PC.
• Standard 4X AAA 1.5V Alkaline bаttеrу or rechargeable Li battery is available for power supply

Main performance

SpO2

Patient: adult, child

Hemoglobin saturation display: 35%-99%

Resolution:1 %

Accuracy: ±2%(70%-99%)  unspecified(0%-69%)

 PR

Range: 0bpm-250bpm

Resolution: 1bpm

Accuracy: ±1bpm

Power Consumption: Smaller than 80mA(Normal)

Low perfusion Condition ≤0.3%

Temperature

Channel                             1

Measuring and Alarm Range        18 ~ 45 °C

Resolution                          0.1°C

Accuracy                                 ±0.1°C

Actualization interval            about 1 Sec.

   Average Time Constant              < 10 Sec

Electrical specifications

Working voltage: DC4.0V-6.0V or 3.5V-4.2V Li battery.

Internal battery: 4 AAA alkaline battery or 1800MAH rechargeable Li battery

Run time: 15-hour continuous operation with a new, fully charged battery (environment temperature is 25℃)

Packing List and Accessories
