🔹 Ergonomic and Mobile Design

• Total weight ≤37 kg including trolley and vaporizer
• Dimensions: 1397mm (H) × 640mm (W) × 634mm (D)
• 4 castors (2 with brakes) for smooth and secure mobility
• Top shelf supports up to 10 kg for additional equipment

🔹 Advanced Digital Interface

• 10.1" capacitive touchscreen with 1024×600 resolution
• Adjustable brightness (5 levels) for optimal visibility
• LED indicators for AC power and system operation
• Audio alarm with 4 priority levels for enhanced safety

🔹 Reliable Power Options

• AC input: 220–240V, 50/60Hz
• Built-in lithium battery (14.8V, 2200mAh) supports ≥60 minutes of operation
• RS232 port for data communication

🔹 High-Precision Pneumatic System

• Dual gas support (oxygen and air) with input pressure: 280–600 kPa
• Flowmeter range: 0–5 L/min with high accuracy
• Mechanical ACGO outlet and oxygen flush (25–75 L/min)

🔹 Efficient Breathing System

• Leakage ≤100 mL/min at 3 kPa
• Standard 22mm/15mm conical ports
• 500 mL CO₂ absorbent canister
• APL valve range: 0–70 cmH₂O
• Mechanical pressure gauge: -20 to 100 cmH₂O (±3% full scale)

🔹 Real-Time Monitoring & Alarms

• Monitored parameters: Vt, MV, Ppeak, PEEP, RR
• High accuracy across all measured values
• Visual and audible alarms for safety assurance

🔹 Wide Environmental Compatibility

• Operating range: 10°C–40°C, 15%–95% RH
• Storage range: -20°C–55°C, 10%–95% RH
• Suitable for varied clinical environments
